Kawasaki RIDGE HVAC

POWER
Engine 4-stroke, DOHC, 4-valve In-Line Four-Cylinder, liquid-cooled
Displacement 999cc
Maximum Horsepower 92.0 hp¹ @ 8,500 rpm
Maximum Torque 65.8 lb-ft @ 5,500 rpm
Bore x Stroke 73.4 x 59.0mm
Compression Ratio 10.6:1
Fuel System EFI
Ignition TCBI with Digital Advance
Starting System Electric
Transmission Continuously Variable Transmission (CVT) with (H,L,N,R)
Final Drive Selectable 4WD with locking rear differential, shaft
Engine Braking Yes
Alternator Output
(max)
85 amp
Electronic Rider Aids Power Modes, Economical Riding Indicator
CAPABILITY
Front Suspension /
Wheel Travel
Long-Travel, Double Wishbone/12.7 in
Rear Suspension /
Wheel Travel
Long-Travel, Double Wishbone/12.7 in
Front Tires Duro 27 x 9-14
Rear Tires Duro 27 x 11-14
Wheel Type 14" Aluminum
Steering Rack-and-pinion w/ Electric Power Steering (EPS)
Front Brakes Dual hydraulic 249mm discs with two-piston calipers
Rear Brakes Dual hydraulic 249mm discs with single-piston calipers
Ground Clearance 12.6/13.6 in (max preload); 12.6 in CA Model
Fuel Capacity 12.9 gal
Turning Radius 15.0 ft
Cargo Bed Dimensions
(LxWxH)
37.6 x 49.0 x 12.8 in
Cargo Bed Load
Capacity
1,000/600 lb CA Model
Payload Capacity 1,499/1,100 lb CA Model
Seating Capacity 3, bench seat
Towing Capacity 2,500 lbs
Lighting All-LED lighting
DETAILS
Frame Ladder type, tubular steel
Overall Length 124.4 in
Overall Width 64.0 in
Overall Height 81.3 in
Curb Weight 2,044.0/2,046.2 lb* CA Model
Wheelbase 90.7 in
Instruments Digital speedometer, tachometer, fuel gauge, odometer, dual
trip meters, total time, trip time, average speed, gear
indicator, Driving Mode, Power Mode, clock, water
temperature, battery voltage, oil change reminder, Bluetooth
indicator, Economical Riding Indicator, maintenance reminder,
high beam, neutral, reverse, and warning lights (battery, EPS,
CVT, seatbelt, parking indicator, oil pressure, water
temperature)
Additional Features Full Cab with HVAC, Adjustable driver's seat, ERGO-FIT®, Fullcolor TFT Instrumentation with Smartphone Connectivity via
RIDEOLOGY THE APP Powersports, USB ports, KQR™ system
compatible
Color Choices Candy Persimmon Red
